Product Details:
|
| Features: | Flat, Solid, Corrosion Resistance, Oxidation Resistance | Weave Type: | Plain Weave, Twilled Weave, Dutch Weave |
|---|---|---|---|
| Material: | SS Wire 201, 304, 304L, 316, 316L, 431, 321 347 Etc. | Wire Diameter: | 0.02mm-5mm |
| Mesh Size: | 0.03-50.8mm | Mesh Count: | Plain Weave Wire Mesh Can Be Woven Up To 400 Mesh. Twill Weave Wire Mesh Can Be Woven From 30 To 635 Mesh. |
| Edge Treatment: | Raw Edge, Selvadge | Length: | 1m-300m |
| Highlight: | 316L Wire Mesh Screen,High Corrosion Resistant Wire Mesh Screen,0.02mm-5mm Dia Wire Mesh Screen |
||
Stainless steel wire mesh screen is a versatile material commonly used in various applications like filtration, protection, and separation. The mesh is made of stainless steel wires woven together to form a uniform and durable surface. It offers excellent corrosion resistance, high tensile strength, and good stability in different environmental conditions. Stainless steel wire mesh screens are used in industries such as mining, food processing, pharmaceuticals, architecture, and many others due to their durability and reliability.
Stainless steel wire mesh screens come in various types, including plain weave, twill weave, dutch weave, and welded mesh. The plain weave is the simplest and most common type, consisting of wires woven in a crisscross pattern. Twill weave has a diagonal pattern, providing higher strength and stability. Dutch weave has different wire diameters for the warp and weft wires, offering excellent filtration capabilities. Welded mesh is made by welding the intersections of wires, creating a strong and stable mesh.
These wire mesh screens can be customized in terms of mesh size, wire diameter, and screen size to suit specific application requirements. They are used for purposes such as filtering liquids and gases, separating solid particles, protecting machinery from debris, and ensuring safety in industrial settings. Stainless steel wire mesh screens are known for their longevity, resistance to corrosion, and easy maintenance, making them a popular choice across various industries.
1. Corrosion Resistance: Stainless steel wire mesh screens are highly resistant to corrosion, making them suitable for use in a wide range of environments, including those with exposure to moisture, chemicals, and extreme temperatures.
2. Strength and Durability: Stainless steel wire mesh screens are known for their high tensile strength and durability, making them ideal for applications where mechanical strength is crucial.
3. Versatility: Stainless steel wire mesh screens are available in various weave patterns, wire diameters, and opening sizes, making them versatile for a wide range of applications. They can be customized to meet specific requirements.
4. High-Temperature Resistance: Stainless steel wire mesh screens can withstand high temperatures, making them suitable for applications involving heat or fire.
5. Easy to Clean: Stainless steel wire mesh screens are easy to clean and maintain, making them ideal for applications where hygiene is important, such as in food processing or pharmaceutical industries.
6. Good Visibility and Airflow: The open weave design of stainless steel wire mesh screens allows for good visibility and airflow, making them suitable for applications where transparency and ventilation are important.
7. Chemical Resistance: Stainless steel wire mesh screens are resistant to many chemicals, making them suitable for applications where exposure to corrosive substances is a concern.
8. Longevity: Stainless steel wire mesh screens have a long service life, making them a cost-effective solution for many applications.
Overall, stainless steel wire mesh screens are a popular choice for various industries due to their durability, corrosion resistance, and versatility.
The stainless mesh screen is available in different apertures ranging from 0.02mm to 50.8mm, with a wire diameter of 0.02mm to 5mm. This makes it suitable for various screening and filtering processes, especially in acid or alkali environments. The plain/twill weave stainless steel wire mesh is commonly used as mud mesh in the oil industry, chemical packing nets, screen mesh in the chemical fiber industry, and pickling nets in the electroplating industry.
With a minimum order quantity of 30sqm and a price range of $75-$110, the stainless mesh screen is available in plain weave, twilled weave, and Dutch weave. It can be used in different scenarios such as:
The stainless mesh screen is packed and delivered securely, rolling around paper-tube first, moisture-proof paper outside, or plastic fabrics. Customized packing is also available. The delivery time is 5-10 days if in stock, and payment terms are T/T and L/C. With a supply ability of 10,000sqm/month, Kingdelong's stainless steel wire mesh screen is a reliable and versatile product for various applications and scenarios.
Q1: What is the brand name of the Stainless Steel Wire Mesh Screen?
A1: The brand name of the Stainless Steel Wire Mesh Screen is Kingdelong.
Q2: Where is the Stainless Steel Wire Mesh Screen produced?
A2: The Stainless Steel Wire Mesh Screen is produced in China.
Q3: What certifications does the Stainless Steel Wire Mesh Screen have?
A3: The Stainless Steel Wire Mesh Screen has ISO 9001, ISO 14001, ISO45001, and SGS certifications.
Q4: What is the minimum order quantity for the Stainless Steel Wire Mesh Screen?
A4: The minimum order quantity for the Stainless Steel Wire Mesh Screen is 30sqm.
Q5: What is the price range of the Stainless Steel Wire Mesh Screen?
A5: The price range of the Stainless Steel Wire Mesh Screen is between $75 to $110.
Q6: What are the packaging details of the Stainless Steel Wire Mesh Screen?
A6: The Stainless Steel Wire Mesh Screen is rolled around a paper tube first and then wrapped with moisture-proof paper or plastic fabrics. Customized packing is also available.
Q7: What is the delivery time for the Stainless Steel Wire Mesh Screen?
A7: If the Stainless Steel Wire Mesh Screen is in stock, the delivery time is 5-10 days.
Q8: What are the payment terms for the Stainless Steel Wire Mesh Screen?
A8: The payment terms for the Stainless Steel Wire Mesh Screen are T/T and L/C.
Q9: What is the supply ability of the Stainless Steel Wire Mesh Screen?
A9: The supply ability of the Stainless Steel Wire Mesh Screen is 10,000sqm/month.
| Mesh | Wire Diameter | Opening | Open Area % | Weight per sq.ft |
| 1 x 1 | .063” | .937” | 87.8 | 0.255 |
| .080” | .920” | 84.6 | 0.411 | |
| .105” | .895” | 80.1 | 0.71 | |
| .135” | .865” | 74.8 | 1.177 | |
| .162” | .838” | 70.2 | 1.702 | |
| .250” | .750” | 56.3 | 4.124 | |
| 3/4 x 3/4 | .054” | .696” | 86.1 | 0.249 |
| .063” | .687” | 83.9 | 0.34 | |
| .080” | .670” | 79.8 | 0.549 | |
| .105” | .645” | 73.9 | 0.95 | |
| .135” | .615” | 67.2 | 1.581 | |
| .162” | .588” | 61.4 | 2.292 | |
| .250” | .500” | 44.4 | 5.623 | |
| 2 x 2 | .047” | .453” | 81.2 | 0.284 |
| .054” | .446” | 79.6 | 0.376 | |
| .072” | .428” | 73.3 | 0.671 | |
| .092” | .408” | 66.6 | 1.102 | |
| .120” | .380” | 57.8 | 1.896 | |
| .148” | .352” | 49.6 | 2.924 | |
| .192” | .308” | 37.9 | 5.055 | |
| 3 x 3 | .032” | .301” | 81.5 | 0.197 |
| .035” | .298” | 79.9 | 0.237 | |
| .047” | .286” | 73.6 | 0.428 | |
| .063” | .270” | 65.6 | 0.776 | |
| .080” | .253” | 57.6 | 1.264 | |
| .105” | .228” | 46.8 | 2.22 | |
| .135” | .198” | 35.3 | 3.776 | |
| 4 x 4 | .025” | .225” | 81 | 0.161 |
| .028” | .222” | 78.9 | 0.202 | |
| .035” | .215” | 74 | 0.317 | |
| .047” | .203” | 65.9 | 0.576 | |
| .063” | .187” | 56 | 1.048 | |
| .080” | .170” | 46.2 | 1.721 | |
| .105” | .145” | 33.6 | 3.062 | |
| .135” | .115” | 21.2 | 5.038 | |
| 5 x 5 | .032” | .168” | 70.6 | 0.332 |
| .041” | .159” | 63.2 | 0.549 | |
| .054” | .146” | 53.3 | 0.967 | |
| .072” | .128” | 41 | 1.764 | |
| .092” | .108” | 29.2 | 2.834 | |
| .105” | .095” | 22.6 | 3.787 | |
| 6 x 6 | .028” | .139” | 69.6 | 0.305 |
| .035” | .132” | 62.7 | 0.481 | |
| .047” | .120” | 51.8 | 0.882 | |
| .063” | .104” | 38.9 | 1.63 | |
| .080” | .087” | 27.2 | 2.591 | |
| 7 x 7 | .028” | .115” | 64.8 | 0.358 |
| .035” | .108” | 57.2 | 0.565 | |
| .047” | .096” | 45.2 | 1.042 | |
| .063” | .080” | 31.4 | 1.847 | |
| 8 x 8 | .017” | .108” | 74.6 | 0.14 |
| .023” | .102” | 66.6 | 0.27 | |
| .028” | .097” | 60.2 | 0.41 | |
| .035” | .090” | 51.8 | 0.651 | |
| .047” | .078” | 38.9 | 1.209 | |
| .063” | .062” | 24.6 | 2.163 | |
| 9 x 9 | .023” | .088” | 62.7 | 0.311 |
| .032” | .079” | 50.6 | 0.614 | |
| .047” | .064” | 33.2 | 1.382 | |
| 10 x 10 | .020” | .080” | 64 | 0.261 |
| .023” | .077” | 59.3 | 0.347 | |
| .028” | .072” | 51.8 | 0.521 | |
| .035” | .065” | 42.3 | 0.831 | |
| .047” | .053” | 28.1 | 1.484 | |
| .063” | .037” | 13.7 | 2.854 | |
| 12 x 12 | .018” | .065” | 60.8 | 0.255 |
| .023” | .060” | 51.8 | 0.422 | |
| .028” | .055” | 43.6 | 0.635 | |
| .035” | .048” | 33.2 | 1.021 | |
| .047” | .036” | 18.7 | 1.851 | |
| 14 X 14 | .017” | .054” | 57.2 | 0.266 |
| .018” | .053” | 55.1 | 0.299 | |
| .020” | .051” | 51 | 0.372 | |
| .025” | .046” | 41.5 | 0.593 | |
| .032” | .039” | 29.8 | 1.005 | |
| .041” | .030” | 17.6 | 1.65 | |
| 16 x 16 | .016” | .047” | 55.4 | 0.271 |
| .018” | .045” | 50.7 | 0.345 | |
| .023” | .040” | 39.9 | 0.577 | |
| .028” | .035” | 30.5 | 0.836 | |
| .035” | .028” | 19.4 | 1.366 | |
| 18 x 14 | .011” | .045”/.060” | 70.6 | 0.102 |
| 18 x 18 | .009” | .047” | 70.4 | 0.095 |
| .017” | .039” | 48.3 | 0.348 | |
| .020” | .036” | 41.1 | 0.49 | |
| .025” | .031” | 30.3 | 0.75 | |
| .032” | .024” | 18 | 1.294 | |
| 20 x 20 | .009” | .041” | 67.2 | 0.105 |
| .014” | .036” | 51.8 | 0.261 | |
| .017” | .033” | 43.6 | 0.391 | |
| .020” | .030” | 36 | 0.552 | |
| .025” | .025” | 25 | 0.85 | |
| .028” | .022” | 19.4 | 1.093 | |
| 24 x 24 | .0075” | .034” | 67.4 | 0.088 |
| .010” | .032” | 57.9 | 0.158 | |
| .020” | .022” | 27.1 | 0.648 | |
| 26 x 26 | .015” | .024” | 37.3 | 0.402 |
| .017” | .022” | 31.2 | 0.526 | |
| .020” | .019” | 23.1 | 0.713 | |
| 28 x 28 | .010” | .026” | 51.8 | 0.186 |
| .0135” | .022” | 38.6 | 0.349 | |
| 30 x 30 | .007” | .027” | 64.8 | 0.084 |
| .0075” | .026” | 59.9 | 0.111 | |
| .008” | .025” | 57.6 | 0.126 | |
| .015” | .018” | 30.1 | 0.474 | |
| .016” | .017” | 26.9 | 0.618 | |
| 35 x 35 | .011” | .018” | 37.9 | 0.29 |
| .012” | .017” | 33.8 | 0.35 | |
| .014” | .015” | 26.1 | 0.465 | |
| 40 x 40 | .0065” | .019” | 54.8 | 0.113 |
| .007” | .018” | 51.8 | 0.13 | |
| .0075” | .018” | 49 | 0.15 | |
| .011” | .014” | 31.4 | 0.338 | |
| .012” | .013” | 27 | 0.409 | |
| .013” | .012” | 23 | 0.488 | |
| 50 x 50 | .0055” | .015” | 52.6 | 0.101 |
| .0075” | .013” | 39.1 | 0.192 | |
| .008” | .012” | 36 | 0.221 | |
| .011” | .009” | 20.3 | 0.42 | |
| .012” | .008” | 16 | 0.511 | |
| 60 x 60 | .0045” | .012” | 53.3 | 0.081 |
| .006” | .011” | 41.2 | 0.147 | |
| .0065” | .010” | 37.5 | 0.174 | |
| .0095” | .007” | 18.7 | 0.379 | |
| .010” | .007” | 16.2 | 0.426 | |
| .011” | .006” | 11.7 | 0.529 | |
| 70 x 70 | .0037” | .0106” | 54.9 | 0.06 |
| .006” | .008” | 33.8 | 0.175 | |
| .0085” | .006” | 16.5 | 0.358 | |
| .009” | .005” | 13.8 | 0.407 | |
| 80 x 80 | .0037” | .0088” | 49.6 | 0.069 |
| .005” | .008” | 36 | 0.138 | |
| .0055” | .007” | 31.4 | 0.169 | |
| .006” | .007” | 27 | 0.204 | |
| .0065” | .006” | 23 | 0.232 | |
| .007” | .006” | 19.4 | 0.274 | |
| .0075” | .005” | 16 | 0.319 | |
| 90 x 90 | .0035” | .0076” | 47.8 | 0.073 |
| .005” | .006” | 30.1 | 0.158 | |
| .0055” | .006” | 25.4 | 0.184 | |
| .006” | .005” | 21.1 | 0.224 | |
| 100 x 90 | .004” | .006”/.0071” | 38.5 | 0.112 |
| .0045” | .0055”/.0066” | 32.7 | 0.117 | |
| 100 x 100 | .0022” | .0078” | 60.8 | 0.049 |
| .003” | .007” | 49 | 0.06 | |
| .0035” | .007” | 42.3 | 0.083 | |
| .004” | .006” | 36 | 0.11 | |
| .0045” | .006” | 30.3 | 0.142 | |
| .005” | .005” | 25 | 0.17 | |
| 120 x 120 | .0026” | .0057” | 48.4 | 0.05 |
| .0035” | .005” | 33.2 | 0.1 | |
| .0037” | .0046” | 30.5 | 0.103 | |
| .0040” | .0043” | 26.8 | 0.132 | |
| 145 x 145 | .0022” | .0048” | 46.4 | 0.049 |
| 150 x 150 | .0026” | .0041” | 37.8 | 0.072 |
| .003” | .0037” | 30.4 | 0.093 | |
| 165 x 165 | .0019” | .0041” | 47.1 | 0.042 |
| 180 x 180 | .0018” | .0038” | 46 | 0.047 |
| .0023” | .0033” | 34.7 | 0.067 | |
| 200 x 200 | .0016” | .0035” | 46.2 | 0.036 |
| .0021” | .0029” | 33.6 | 0.063 | |
| .0023” | .0027” | 49.2 | 0.073 | |
| 230 x 230 | .0014” | .0029” | 46 | 0.031 |
| 250 x 250 | .0014” | .0026” | 42.3 | 0.035 |
| .0016” | .0024” | 36 | 0.041 | |
| 270 x 270 | .0014” | .0023” | 38.6 | 0.037 |
| .0016” | .0021” | 32.1 | 0.048 | |
| 280 x 280 | .0014” | .0022” | 38 | 0.039 |
| 300 x 300 | .0012” | .0021” | 41 | 0.03 |
| .0015” | .0018” | 29.2 | 0.047 | |
| 325 x 325 | .0011” | .0020” | 41.6 | 0.029 |
| .0014” | .0017” | 30.5 | 0.043 | |
| 400 x 400 | .0010” | .0015” | 38 | 0.028 |
| .0011” | .0014” | 31.4 | 0.034 | |
| 500 x 500 | .0010” | .0010” | 26 | 0.033 |
| 635 x 635 | .0008” | .0008” | 25.8 | 0.027 |
