Product Details:
|
| Netting: | In Panels Or Rolls | Application: | Construction Wire Mesh, Protecting Mesh, Cages |
|---|---|---|---|
| Weight Capacity: | 2500 LBS | Color: | Natural Color Or Painting Color |
| Packing: | On Pallet Or In Bulk,wrapped With Shrink Film. | Material: | Low Carbon Steel, Galvanized Steel, Stainless Steel |
| Hole Shape: | Square, Rectangular | Aperture: | 1/4" Upto 3" |
| Highlight: | painting 1/2 inch welded wire panels,natural color welded wire panels,1/2 inch welded wire fence panels |
||
This product is a type of welded wire fabric sheet, also known as reinforcement mesh sheets, used for various applications in construction, agriculture, and other industries. It is a versatile and durable solution for reinforcing concrete structures, fencing, and other purposes.
Our Welded Wire Mesh Panels have a maximum weight capacity of 2500 LBS, making them suitable for heavy-duty applications. The mesh panels are available in both panels and rolls, providing flexibility in use and installation. The panels are pre-cut to standard sizes, while the rolls can be customized to fit specific project needs. The mesh size of our Welded Wire Mesh Panels is 1/4 inch, providing a fine and uniform opening that allows for efficient and precise reinforcement.
Whether you need to reinforce concrete structures, create secure fencing, or have other uses in mind, our Welded Wire Mesh Panels offer a reliable and cost-effective solution. With its high weight capacity, versatile netting options, precise aperture size, and sturdy welded style, it is a product you can trust to get the job done.
| Commonly Used Specifications | ||||
| Mesh Opening in (Center to Center) | Wire Diameter | Panel Size in | Material | |
| in | mm | |||
| 1/4“ | 0.032 | 0.8 | 48" x 1200" | Stainless Steel 304 |
| 1/4“ | 0.025 | 0.6 | 36" x 1200" | Galvanized After |
| 1/2" | 0.041 | 1.0 | 36" x 1200" | Galvanized After |
| 1/2" | 0.041 | 1.0 | 48" x 1200" | Galvanized After |
| 1/2" | 0.063 | 1.6 | 48" x 1200" | Stainless Steel 304 |
| 1/2" | 0.063 | 1.6 | 60" x 1200" | Galvanized After |
| 1/2" | 0.041 | 1.0 | 72" x 1200" | Galvanized After |
| 1/2" | 0.041 | 1.0 | 60" x 1200" | Galvanized After |
| 1" | 0.122 | 3.1 | 72" x 144" | Galvanized After |
| 1" | 0.08 | 2.0 | 48" x 1200" | Pre-Galvanized |
| 1" | 0.063 | 1.6 | 48" x 1200" | Pre-Galvanized |
| 1" | 0.105 | 2.7 | 48" x 96" | Carbon Steel |
| 1" | 0.118 | 3.0 | 48" x 120" | Carbon Steel |
| 1" | 0.118 | 3.0 | 48" x 96" | Carbon Steel |
| 1" | 0.118 | 3.0 | 60" x 120" | Carbon Steel |
| 1" | 0.101 | 2.6 | 48" x 96" | Galvanized After |
| 1" | 0.122 | 3.1 | 48" x 96" | Galvanized After |
| 1-1/2" | 0.135 | 3.4 | 48" x 120" | Carbon Steel |
| 1-1/2" | 0.135 | 3.4 | 60" x 120" | Carbon Steel |
| 1-1/2" | 0.118 | 3.0 | 48" x 96" | Carbon Steel |
| 1-1/2" | 0.118 | 3.0 | 48" x 120" | Carbon Steel |
| 2" | 0.25 | 6.4 | 48" x 120" | Carbon Steel |
| 2" | 0.122 | 3.1 | 72" x 144" | Galvanized After |
| 2" | 0.189 | 4.8 | 48" x 96" | Galvanized After |
| 2" | 0.159 | 4.0 | 48" x 96" | Galvanized After |
| 2" | 0.122 | 3.1 | 72" x 144" | Galvanized After |
| 2" | 0.122 | 3.1 | 60" x 120" | Galvanized After |
| 2" | 0.122 | 3.1 | 48" x 96" | Galvanized After |
| 2" | 0.122 | 3.1 | 48" x 120" | Galvanized After |
| 2" | 0.101 | 2.6 | 48" x 96" | Galvanized After |
| 2" | 0.118 | 3.0 | 48" x 96" | Carbon Steel |
| 2" | 0.118 | 3.0 | 60" x 120" | Carbon Steel |
| 2" | 0.063 | 1.6 | 48" x 1200" | Galvanized After |
| 2" | 0.118 | 3.0 | 72" x 144" | Carbon Steel |
| 2" | 0.135 | 3.4 | 48" x 120" | Carbon Steel |
| 2" | 0.105 | 2.7 | 48" x 96" | Carbon Steel |
| 2" | 0.135 | 3.4 | 48" x 96" | Carbon Steel |
| 2" | 0.118 | 3.0 | .118" | Carbon Steel |
| 2" | 0.135 | 3.4 | 60" x 120" | Carbon Steel |
| 2" | 0.155 | 3.9 | 48" x 96" | Carbon Steel |
| 2" | 0.155 | 3.9 | 60" x 120" | Carbon Steel |
| 2" | 0.187 | 4.7 | 60" x 120" | Carbon Steel |
| 2" | 0.25 | 6.4 | 60" x 120" | Carbon Steel |
| 2" | 0.25 | 6.4 | 48" x 96" | Carbon Steel |
| 2" | 0.118 | 3.0 | 48" x 120" | Carbon Steel |
| 2" | 0.187 | 4.7 | 48" x 120" | Carbon Steel |
| 2" | 0.187 | 4.7 | 48" x 96" | Carbon Steel |
| 3" | 0.162 | 4.1 | 48" x 120" | Carbon Steel |
| 3" | 0.162 | 4.1 | 48" x 96" | Carbon Steel |
| 3" | 0.162 | 4.1 | 48" x 144" | Carbon Steel |
| Product Name | Welded Wire Mesh Panels |
|---|---|
| Packing | On Pallet or In Bulk, Wrapped with Shrink Film |
| Aperture | 1/4" to 3" |
| Hole Shape | Square, Rectangular |
| Netting | In Panels or Rolls |
| Color | Natural Color or Painting Color |
| Wire Dia. | From 0.8mm up to 5.5mm |
| Welded Style | Spot Welded |
| Application | Construction Wire Mesh, Protecting Mesh, Cages |
| Material | Low Carbon Steel, Galvanized Steel, Stainless Steel |
| Weight Capacity | 2500LBS |
| Reinforcement Mesh Sheets | Yes |
| Electric Welded Wire Panels | Yes |
| Wire Mesh Fencing | Yes |
Are you in need of a strong and durable solution for your reinforcement or fencing needs? Look no further than KDL's Welded Wire Mesh Panels. Our panels are made from high-quality fused wire mesh, offering superior strength and longevity for a variety of applications.
No matter the application or scenario, our Welded Wire Mesh Panels are the perfect solution for all your reinforcement and fencing needs.
Welded wire mesh panels are carefully packed in wooden crates or pallets to prevent damage during shipment. Every panel is securely fastened to the crate with steel bands to ensure that it stays in place during transit. The crates are then wrapped in plastic to protect the panels from moisture and other elements.
For smaller orders, the panels may be packaged in strong cardboard boxes with additional padding for added protection. Each box is labeled with the product name, size, and quantity for easy identification.
When shipping internationally, the panels are loaded into shipping containers and secured with straps to prevent movement. Our team takes great care in ensuring that the panels are packed and shipped safely to their final destination.
Customers can also choose to have their panels shipped via air or sea freight, depending on their preferences and delivery time requirements.
We strive to provide efficient and reliable shipping services to our customers, and we work closely with our trusted shipping partners to ensure timely and safe delivery of our products.
